Siemens LME71.000A1 110v Microprocessor Burner Controls
$205.59
Sale price
$205.59
Regular price
$267.00
Skip to product information
<>
<>
Siemens LME71.000A1 110v Microprocessor Burner Controls
$205.59
Sale price
$205.59
Regular price
$267.00
Siemens LME71.000A1 Burner Control Box 110V
Overview
The burner controlLME71.000A1 is a microprocessor-based unit with matching system components for the control and supervision of forced draft burners of medium to high capacity.
The fuel-air ratio can be set either via an air damper actuator - acting on mechanical or pneumatic ratio control - or via pulse width modulated fans and pneumatic ratio control. The flame supervision supervised with ionization probe and with UV flame detector QRA2..., QRA4.U or QRA10...
LME71.000A1 Burner Control Box Applications
The LME71 is used for the startup and supervision of multistage or modulating forced draft burners and atmospheric gas burners in intermittent operation.
Features
- Prepurge Time: 9s
- Safety Time: 5s
- Pre-ignition time: 2s
- Undervoltage detection
- Supply Voltage: 110VAC
- Electrical remote reset facility
- IP Rating: IP40
- Operation Temperature: -20 - +60
- Multicolor indication of fault status and operating state messages
- Weight: Approx. 490g
Dimensions
| Control Box | Height | Width | Depth |
|---|---|---|---|
| LME71.000A1 230V | 180mm | 120mm | 52.6mm |
