Siemens AGK11.7 Plug-in Burner Control Box Base

Siemens Part Number: BPZ:AGK11.7

Use for LFS1 flame safeguard

• Colour: black
• Made of impact-proof and heat-resistant plastic
• With separating plate (D) for safe isolation
• With moulded terminal chamber no. 8 for safe isolation
• Accommodates (in addition to the 12 connection terminals):
• 3 neutral terminals, pre-wired to terminal 2, the neutral input
• 4 earth conductor terminals, joining in a lug for earthing the burner
• 2 auxiliary terminals marked «31» and «32»
• With 2 holes in the baseplate of the AGK11 for cable entry
• Provided with catches on the 2 narrow sides which audibly engage when the burner control is plugged in
• To disengage, a screwdriver must be slightly tilted in the guiding slots
• Neutral and auxiliary terminals with self-tapping screws
• Connection terminals with self-locking screws
• Supplied with terminals open to facilitate mounting
• The burner control is secured to the burner with fixing screws M5

Dimensions
