Cofi TRS 1020 Ignition Transformer

TRS 1020 - 10kV Dual Outlet Intermittent Transformer

High Voltage 10kV/20mA Dual Outlet Intermittent Inductive Transformer

The TRS 1020 steps up to 10kV output while maintaining 20mA current capacity across two outlets. Engineered for applications requiring higher voltage potential with intermittent duty cycle reliability.

Key Technical Specifications:

• Output Voltage: 10kV (increased voltage rating)
• Current Rating: 20mA
• Operation Type: Intermittent duty
• Outlets: 2 high-voltage outlets
• Supply Voltage: 230VAC, 50Hz
• Supply Cable: 3 x 0.75 mm² conductors
• Overall Length: 440mm (380mm useable length)
• Weight: Approximately 1.8kg
• Insulation Class: Class H windings
• Encapsulation: Epoxy resin protection
• Compliance: EC Approval certified
• Mounting: Flush self-tapping screw outlets (13mm deep)

Excellent for high-voltage testing, electrostatic applications, and systems requiring elevated voltage levels with dual-outlet convenience.
