Cofi TRE 820P Ignition Transformer

TRE 820P - Standard Single Outlet Transformer

Reliable 8kV/20mA Single Outlet Intermittent Inductive Transformer

The TRE 820P delivers dependable 8kV output at 20mA through a single outlet, providing proven performance for standard intermittent duty applications. Built with premium Class H windings and robust construction for consistent reliability.

Key Technical Specifications:

• Output Voltage: 8kV
• Current Rating: 20mA
• Operation Type: Intermittent duty
• Outlets: 1 high-voltage outlet
• Supply Voltage: 230VAC, 50Hz
• Supply Cable: 3 x 0.75 mm² conductors
• Overall Length: 440mm (380mm useable length)
• Weight: Approximately 2.8kg (heavy-duty construction)
• Insulation Class: Class H windings
• Encapsulation: Epoxy resin protection
• Compliance: EC Approval certified
• Mounting: Flush self-tapping screw outlet (13mm deep)

Ideal for standard high-voltage applications, electronic equipment testing, and industrial processes requiring reliable 8kV intermittent operation.
